  MIG/ARC 630 IJ

  MODEL: MIG/ARC  630 IJ   3 Phase  IGBT Module

   SPECIFICATION :

  INPUT VOLTAGE (v)                        AC415v±15%
  INPUT POWER CAPACITY (KVA)              35
  OUTPUT VOLTAGE ADJUSTMENT (V)     44
  OUTPUT CURRENT RANGE (A)                 80 – 630
  WIRE FEEDER SPEED (MTR/MIN)            3 – 24
  POWER FACTOR                                         0.93
  NET WEIGHT  (KG)                                     44
  DIMENSION (INCH)                                   25.5 X 12 X 25
  MIG WIRE DIAMETER  (MM)                  0.8 – 1.6

  Read more
•

  Read more

  ARC400 IJ

  MODEL: ARC 400 IJ 3 Phase IGBT Module

  SPECIFICATION :

  • INPUT VOLTAGE (v) AC415v±15%
  • INPUT POWER CAPACITY (KVA) 18
  • NO-LOAD VOLTAGE (V) 68
  • OUTPUT CURRENT RANGE (A) 30 – 400
  • RATE INPUT CURRENT (A) 17
  • POWER FACTOR 0.93
  • NET WEIGHT (KG) 26
  • DIMENSION (INCH) 21.5 X 11 X 21.5
  • PLATE THICKNESS (MM) 2.0 – 40.0
  • ELECTRODE SIZE (MM) 2.0 – 6.0

  Read more
•

  Read more

  50-D-OX-PROUD

  Single Stage Double Gauge Oxygen Gas Pressure Regulator

  • Brass forging body
  • Aluminum pressure die-casting bonnet
  • Neoprene rubber diaphragm
  • SS net inlet filter
  • Dual safety pressure gauges
  • In-built safety valve
  • Use for Welding, Cutting, Heating & Brazing
  • ISI Mark : IS 6901/ ISO 2503 & CE certified
